TDS25, TDS30, TDS35

TDS25 [ 1.5~3.5tons ] [ For small-sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS25
Evaporator Unit
TDS25
Condenser Unit
  • R404A
Refrigeration Capacity
(Ambient Temp:35oC)
Temperature inside the cargo room TDS25
0oC 2,900W
-18oC 1,750W
-25oC 1,300W

Specifications

Model TDS25
Refrigerant R404A
Capacity
(ATP condition at 35oC ambient)		 0oC 2,900W
-18oC 1,750W
-25oC 1,300W
Compressor CS55
Weight 64kg

TDS30 [ 1.5~3.5tons ] [ For small-sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS30
Evaporator Unit
TDS30
Condenser Unit
  • R404A
Refrigeration Capacity
(Ambient Temp:35oC)
Temperature inside the cargo room TDS30
0oC 3,400W
-18oC 2,100W
-25oC 1,650W

Specifications

Model TDS30
Refrigerant R404A
Capacity
(ATP condition at 35oC ambient)		 0oC 3,400W
-18oC 2,100W
-25oC 1,650W
Compressor CS90
Weight 67kg

TDS35 [ 1.5~3.5tons ] [ For small-sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS35
Evaporator Unit
TDS35
Condenser Unit
  • R404A
Refrigeration Capacity
(Ambient Temp:35oC)
Temperature inside the cargo room TDS35
0oC 3,650W
-18oC 2,250W
-25oC 1,750W

Specifications

Model TDS35
Refrigerant R404A
Capacity
(ATP condition at 35oC ambient)		 0oC 3,650W
-18oC 2,250W
-25oC 1,750W
Compressor CS90
Weight 72kg
