TDS40, TDS50

TDS40 [ 3~4tons ] [ For small-medium sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS40 — Evaporator Unit

TDS50 — Condenser Unit

Refrigeration Capacity
(Ambient Temp:35^oC)

Temperature inside the cargo room TDS40
0^oC	4,300W
-18^oC	2,600W
-25^oC	2,000W

Specifications

Model		TDS40
Refrigerant		R404A
Capacity (ATP condition at 35^oC ambient)	0^oC	4,300W
	-18^oC	2,600W
	-25^oC	2,000W
Compressor		CS90
Weight		81kg

TDS50 [ 3~4tons ] [ For small-medium sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS30 — Evaporator Unit

TDS30 — Condenser Unit

Refrigeration Capacity
(Ambient Temp:35^oC)

Temperature inside the cargo room TDS50
0^oC	4,850W
-18^oC	2,900W
-25^oC	2,250W

Specifications

Model		TDS50
Refrigerant		R404A
Capacity (ATP condition at 35^oC ambient)	0^oC	4,850W
	-18^oC	2,900W
	-25^oC	2,250W
Compressor		CS90
Weight		85kg
