TDS60, TDS70

TDS60 [ 4~tons ] [ For medium sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS60 — Evaporator Unit

TDS60 — Condenser Unit

Refrigeration Capacity
(Ambient Temp:35^oC)

Temperature inside the cargo room TDS60
0^oC	5,800W
-18^oC	3,550W
-25^oC	2,850W

Specifications

Model		TDS60
Refrigerant		R404A
Capacity (ATP condition at 35^oC ambient)	0^oC	5,800W
	-18^oC	3,550W
	-25^oC	2,850W
Compressor		CS90E
Weight		105kg

TDS70 [ 4~tons ] [ For medium sized trucks ] [ Single ] [ Multi ] [ For chilled and frozen ]

TDS70 — Evaporator Unit

TDS70 — Condenser Unit

Refrigeration Capacity
(Ambient Temp:35^oC)

Temperature inside the cargo room TDS70
0^oC	7,100W
-18^oC	4,050W
-25^oC	3,000W

Specifications

Model		TDS70
Refrigerant		R404A
Capacity (ATP condition at 35^oC ambient)	0^oC	7,100W
	-18^oC	4,050W
	-25^oC	3,000W
Compressor		CS90E
Weight		128kg
